DMTA-10040-01EN, Rev. E, February 2018
Chapter 6310
Commands may be read (R), written (W) or executed (X). Table 7 on page 310 lists the
commands and the format in which they must be written.
3. In the Issue Command dialog box, click Send (see Figure 6-18 on page 309).
OR
Press Enter on your PC keyboard.
The NORTEC 600 remote command convention is as follows:
— Read (R) commands end with “?”
Example: AN1?
— Write (W) commands include “=” followed immediately by a value without
any spaces
Example: AN1=45
— Execute (X) commands include only the command
Example: DLB
All commands end with a carriage return and line feed (entered as “\r\n”). Any
space in a Write command should be replaced with an underscore character.
Table 7 NORTEC 600 remote commands
Command Description R/W/X
Range/valid strings
Min Max
ADW Alarm Dwell R/W 0.005 10.000
AN1 Angle 1 R/W 0.000 359.900
AN2 Angle 2 R/W 0.000 359.900
ANI Angle Step Increment R/W 0.100
ASE Sweep Erase R/W ON/OFF
AST Auto Sweep Time R/W 0.005 10.000
