FQ2-S/CH User’s Manual
177
4
Setting Up Inspections
Measurement Data That Can Be Used for External Outputs and Calculations
The following values can be used as measurement data and output to external devices via Ethernet or used in
calculations.
Expression
text string
Data name Description Data range
JG Judgement This is the judgement result.
-2: No judgment (not measured)
0: Judgment is OK
-1: Judgment is NG
-11: Model does not match
-13: Measurement time out
-16: Measurement timeout error,
-17: Format not entered error
IN Index This is the verification result
(i.e., the master data number).
−2: No verification pattern,
or reading error
−1: Verification is NG
0 to 31: Master data No.
N Number of read characters This is the total number of characters
that were read for all four lines.
0 to 128
SIM Similarity This is the lowest similarity of the read
characters.
0 to 100
STB Stability This is the lowest stability of the read
characters.
0 to 100
N1 Number of read characters
(line 1) N1
This is the number of read characters
for line 1.
0 to 32
N2 Number of read characters
(line 2) N2
This is the number of read characters
for line 2.
0 to 32
N3 Number of read characters
(line 3) N3
This is the number of read characters
for line 3.
0 to 32
N4 Number of read characters
(line 4) N4
This is the number of read characters
for line 4.
0 to 32
SM Individual similarity This is the similarity of read character
N (N = 0 to 127).
0 to 100
SB Individual stability This is the stability of read character
N (N = 0 to 127).
0 to 100
SMC Similarity (each character type)
Similarity level of loaded characters.
(N= 0 to 39)
N= 0 to 9: 0 to 9
10 to 35: A to Z
36: / (slash)
37: : (colon)
38・39; (, ) (parenthesis)
0 to 100
SBC Stability (each character type)
Stability level of loaded characters.
(N= 0 to 39)
N= 0 to 9: 0 to 9
10 to 35: A to Z
36: / (slash)
37: : (colon)
38・39; (, ) (parenthesis)
0 to 100
