Menu Tables
FQ2-S/CH User’s Manual
465
Appendices
9
Test Tab Page
Menu command Description Setting range Data
Continuous test
Used to check the individual judgment
results for the inspection items and to
adjust the judgment parameters.
--- ---
p. 340
Graphic Displays the input image.
Graphics + Details Displays the inspection item individual
judgment results and measurement val-
ues.
All results/Region Displays the inspection item individual
judgment results for all inspection items.
p. 349
Trend Monitor Displays the individual judgment results
saved in the Sensor in a trend monitor. p. 340
p. 358
Histogram Displays the individual judgment results
saved in the Sensor in a histogram.
Model region Same as for the Search item settings. Scene
---
Insp. region Scene
Adjust judgement Adjusts judgment parameters without
stopping measurements.
---
Scene
p. 346
Result type Specifies the measurement result type. Absolute value (Default)
Relative value
Ratio
p. 346
Continuous test
Display setting Specifies whether to display individual
inspection results.
Area, Labeling
  Measurement image
  All color image (Default)
  Selected color image
  Binary image
When the Shape Search lll..
  Meas. Img.
  Meas. Img.+Model Img.
  Edge Image
  Edge Img.+ Model Img.
Scene p. 346
Auto judgement con-
dition setting
Automatically adjusts the judgment
parameters by using actual workpieces
which are considered as good or faulty
products.
OK Teach
NG Teach
Method Selects the expression to use to auto-
matically adjust the judgment parame-
ters.
Threshold (minimum)
Threshold (average) (Default)
Threshold (maximum)
Auto display (trend
monitor and histo-
gram only)
Same as the trend monitor and histogram for [Run] Mode. ---
p. 358
p. 360
Display range (trend
monitor and histo-
gram only)
Number of data
(trend monitor only)
p. 358
Number of data
(histogram only)
p. 360
Erase display ---
Save data Saves scene data, Calibration data, and
system data.
--- --- p. 350
