Startup Display and Display Elements
30
FQ2-S/CH User’s Manual
Display Elements
This Sensor has a Setup Mode and a Run Mode.
Refer to 9-1 Menu Tables: p. 438
4 When the Sensor is detected, the following display will appear.
• The Setup Mode will appear if a Sensor that has not been
set up is connected.
• The Run Mode will appear if a Sensor that has been set
up is connected.
When the Touch Finder is started, IP addresses are automatically set for each Sensor.
To allocate specific IP addresses, set the IP address of each Sensor and the Touch Finder.
2-6 Setting Up Ethernet: p.67
Note
To Next Page
