Omron FQ2-S/CH Series

Inspecting with the Area Inspection Item
300
FQ2-S/CH User’s Manual
4-16 Inspecting with the Area Inspection Item
FQ2-S1
FQ2-S2
FQ2-S3 FQ2-S4
Area Inspection Item
This inspection item is used to measure sizes. It measures the amount of a color within the measurement
region. The size is calculated as a number of pixels and it is called the area.
OK NG
Judges according to the
number of pixels (area) of the
specified color.
Specified color
Measurement region
Sample Settings Sample Measurement
