SD Card Operations
FQ2-S/CH User’s Manual
409
7
Convenient Functions
7-8 SD Card Operations
FQ2-S1
FQ2-S2
FQ2-S3 FQ2-S4
FQ2-CH
With an FQ2 Sensor, the following folders are automatically created in the SD card according to the data that is
saved. The specified data is saved in files in these folders.
*1 : For the PC Tool, data will be saved in the following folder: \\..\My Documents\OMRON FQ\SDCard\
*2 : Only supported on the FQ2-S4/CH Series.
Storage folder
*1
Data
\sensor_name\SCN Scene data (The file name extension is SCN.)
\sensor_name\SGP Scene group data (The file name extension is SGP.)
\sensor_name\DIC
*2
Dictionary data (The file name extension is DIC.)
\sensor_name\DGP
*2
All dictionary data (The file name extension is DGP.)
\sensor_name\CODE
*2
All dictionary data (The file name extension is CSV.)
\sensor_name\SYD Sensor system data (The file name extension is SYD.)
\sensor_name\BKD All sensor data (The file name extension is BKD.)
\sensor_name\CLB Calibration data (The file name extension is CLB.)
\sensor_name\CGP Calibration data (The file name extension is CGP.)
\MSD Touch Finder data (The file name extension is MSD.)
\sensor_name\LOGIMAGE Image data (The file name extension is IFZ.)
\sensor_name\LOGDATA Statistical data and measurement data (The file name extension is
CSV.)
\CAPTURE Captured images (The file name extension is BMP.)
Camera image data (The file name extension is IFZ.)
• The PC Tool does not support SD card operations.
• To display an image file saved in an SD card, refer to the following.
• Use SD card formatted as FAT or FAT32. Touch Finder will not recognize other formats.
(Setup Mode) − − [Logging image file] or [Camera image file]
Display Functions - Displaying a Saved Image: p. 382
