Inspecting with the Sensitive Search Inspection Item
270
FQ2-S/CH User’s Manual
Measurement Data That Can Be Logged
The following values can be logged as measurement data.
* When logging data is output, the data is output in the order of the above table.
7-6 Logging Measurement Data and Image Data: p. 392
Errors
Errors in Teaching
A teaching error message will appear if the contrast of the image within the model registration region is too low.
Select a region with a larger contrast between light and dark areas compared to the region that was registered
as the model and re-register it as the model.
Parameter Range of value Description
Judgement
−2: No judgment (not measured)
0: Judgment is OK
−1: Judgment is NG
This is the judgment result of the sensitive search.
Correlation 0 to 100 Correlation
D deviation Color image: 0 to 221
Monochrome image: 0 to 127
Density deviation
Position X −99,999.9999 to 99,999.9999 This is the X coordinate of the position where the
model was found.
Position Y −99,999.9999 to 99,999.9999 This is the Y coordinate of the position where the
model was found.
Angle −180 to 180 This is the angle of the position where the model was
found.
NG sub-region 0 to 100 This is the number of NG sub-regions.
Sub-region number 0 to 99 This is the number of the regions with the lowest cor-
relation.
Sub-region pos. X
(sub-region number (X))
0 to 9 This is the column number in the X direction of the
output region.
Sub-region pos. Y
(sub-region number (Y))
0 to 9 This is the row number in the Y direction of the output
region.
Sub-region position X −999,999,999.9999 to
999,999,999.9999
This is the X coordinate of the sub-region that was
found.
Sub-region position Y −999,999,999.9999 to
999,999,999.9999
This is the Y coordinate of the sub-region that was
found.
Correlation
(sub-region)
0 to 100 Correlation
Deviation
(sub-region)
Color image: 0 to 221
Monochrome image: 0 to 127
Density deviation
To Next Page
