Menu Tables
466
FQ2-S/CH User’s Manual
Run Tab Page (from Setup Display)
Tool
Setup Mode
Menu command Description Setting range Data
Switch to Run mode Switches to Run Mode. --- --- p. 353
Menu command Description Setting range Data
Select scene --- ---
p. 366
Select Switches to a registered scene. --- Scene
Rename
Used to delete, copy, or change the name
of a scene.
15 alphanumeric characters
---
Copy
---
Clear
Calibration*
2
Select Sets a registered calibration pattern. Calibration data 0 to 31 --- ---
Modify Used to edit calibration data. Calibration data 0 to 31 Calibra-
tion data
---
Specify point
Sets the type of calibration data to set. Specify point (No. 1 to No. 9)
--- p. 371
Reference --- p. 374
Parameter --- p. 377
Modify Sets the parameters for the calibration
data.
--- --- ---
(Specify point)
Specify point coord.
Sets the Camera coordinates. ---
Calibra-
tion data
p. 371
Actual coord.
Sets the Camera coordinates and the
actual coordinates.
Point coordinate: 0 to 9999
Actual coordinate: 0 to 99999.9999
Calibra-
tion data
Generate parameters
Used to create calibration parameters. --- Calibra-
tion data
