Page #503 background image
External Reference Parameters
FQ2-S/CH User’s Manual
501
Appendices
9
Position Compensation (Image Rotation, Parameter)
*1: Depends on the model. Refer to Compensating for Position Offset (Position Compensation Items): p. 102.
External
refer-
ence
number
Category Data name Set / Get Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
0
Measure-
ment
result
Judgement Get only −2: No judgement
(not measured)
0: Judgement is OK
−1: Judgement is NG
−2 JG ---
5 Scroll X Get only −99999.9999 to 99999.9999 0 DX ---
6 Scroll Y Get only −99999.9999 to 99999.9999 0 DY ---
7 Scroll θ Get only −180.0000 to 180.0000 0 DT ---
8 Position X Get only −99999.9999 to 99999.9999 0 X ---
9 Position Y Get only −99999.9999 to 99999.9999 0 Y ---
10 Angle Get only −180.0000 to 180.0000 0 TH ---
11 Reference X Get only −99999.9999 to 99999.9999 0 SX ---
12 Reference Y Get only −99999.9999 to 99999.9999 0 SY ---
13 Reference angle Get only −180.0000 to 180.0000 0 ST ---
200
Measure-
ment
conditions
Ref. position X
(reference position X)
Set / Get −99999.9999 to 99999.9999 *
1
--- ---
201 Ref. position Y
(reference position Y)
Set / Get −99999.9999 to 99999.9999 *
1
--- ---
202 Ref. position θ
(reference position θ)
Set / Get −180.0000 to 180.0000 90 --- ---
203 Measurement position
X
Set / Get −99999.9999 to 99999.9999 *
1
--- ---
204 Measurement position
Y
Set / Get −99999.9999 to 99999.9999 *
1
--- ---
205 Measurement position
θ
Set / Get −180.0000 to 180.0000 0 --- ---
