Convenient Functions for Setup
420
FQ2-S/CH User’s Manual
7-10Convenient Functions for Setup
FQ2-S3 FQ2-S4
This section describes the functions that can be used when setting inspection items.
Making Settings with Stored Images
With an FQ2 Sensor, judgment parameters can be set by using the following images.
Images saved in internal Sensor memory.
Image files in an SD card
Saving Image Data
• Temporarily Saving Images in the Sensor
The measured images can be temporarily saved inside the Sensor.
These images are held until the Sensor power supply is turned OFF.
[In/Out] − [Log setting] − [Image logging]
Setting Logging Parameters for Image Data: p. 401
You can also use images that were captured on the display.
Capturing the Displayed Image: p. 415
Note
To Next Page
