Omron FQ2-S/CH Series User Manual

External Reference Parameters
FQ2-S/CH User’s Manual
541
Appendices
9
Color Data (FQ2-S1/S2/S3 series or FQ2-S4 series only)
External
refer-
ence
number
Category Data name Set / Get Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
0Mea-
sure-
ment
result
Judgement Get only −2: No judgement (not measured),
0: Judgement is OK,
−1: Judgement is NG,
−10: Image error,
−13: Teaching not performed error,
−14: Figure not registered error,
−15: Out of range error,
−20: Other error
−2JG ---
5 R average Get only 0 to 255 0 AR ---
6 G average Get only 0 to 255 0 AG ---
7 B average Get only 0 to 255 0 AB ---
8 Color difference Get only 0 to 442
The density average is displayed
for a Monochrome Camera.
0 AD Logged data
9 Color deviation Get only 0 to 221
The standard deviation of the den-
sity is displayed for a Monochrome
Camera.
0DV ---
103 Output
parame-
ter
Reflect Set / Get 0: Yes, 1: No 0 --- ---
124 Judge-
ment
condi-
tions
Color difference upper
limit
Set / Get 0 to 442 442 --- Judgement
condition
125 Color difference lower
limit
Set / Get 0 to 442 0
126 Mea-
sure-
ment
condi-
tions
Color deviation upper
limit
Set / Get 0 to 221 221 --- ---
127 Color deviation lower
limit
Set / Get 0 to 221 0 --- ---
130 Density average upper
limit
Set / Get 0 to 255 255 --- ---
131 Density average lower
limit
Set / Get 0 to 255 0 --- ---
132 Density deviation upper
limit
Set / Get 0 to 127 127 --- ---
133 Density deviation lower
limit
Set / Get 0 to 127 0 --- ---
134 R average upper limit Set / Get 0 to 255 255 --- ---
135 R average lower limit Set / Get 0 to 255 0 --- ---
136 G average upper limit Set / Get 0 to 255 255 --- ---
137 G average lower limit Set / Get 0 to 255 0 --- ---
138 Mea-
sure-
ment
condi-
tions
B average upper limit Set / Get 0 to 255 255 --- ---
139 B average lower limit Set / Get 0 to 255 0 --- ---
