Omron FQ2-S/CH Series

External Reference Parameters
FQ2-S/CH User’s Manual
531
Appendices
9
Shape Search III (FQ2-S1/S2/S3 series or FQ2-S4 series only)
312 Logging
condi-
tions
Data logging switch for
correlation
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
313 Data logging switch for
position X
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
314 Data logging switch for
position Y
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
315 Data logging switch for
measurement angle
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
321 Data logging switch for
detection count
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
700 Display
settings
Correlation display Set / Get 0: Display
1: Do not display
0 --- ---
701 Position X display Set / Get 0: Display
1: Do not display
0 --- ---
702 Position Y display Set / Get 0: Display
1: Do not display
0 --- ---
703 Measurement angle
display
Set / Get 0: Display
1: Do not display
0 --- ---
704 Count display Set / Get 0: Display
1: Do not display
0 --- ---
800 Position X display pat-
tern
Set / Get 0: Absolute value
1: Relative value
0 --- ---
801 Position Y display pat-
tern
Set / Get 0: Absolute value
1: Relative value
0 --- ---
802 Measurement angle
display pattern
Set / Get 0: Absolute value
1: Relative value
0 --- ---
External
refer-
ence
number
Category Data name Set / Get Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
0
Mea-
sure-
ment
result Judgement Get only
−2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
−2 JG Logged data
5 Correlation Get only 0 to 100 0 CR[0] to
CR[31]
Logged data
6 Position X Get only −99,999.9999 to 99,999.9999 0 X[0] to
X[31]
Logged data
7 Position Y Get only −99,999.9999 to 99,999.9999 0 Y[0] to
Y[31]
Logged data
8 Angle Get only −180 to 180 0 TH[0] to
TH[31]
Logged data
External
refer-
ence
number
Category Data name Set / Get Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
