Omron FQ2-S/CH Series User Manual

External Reference Parameters
532
FQ2-S/CH User’s Manual
9 Mea-
sure-
ment
result
Reference X Get only −99,999.9999 to 99,999.9999 0 SX ---
10 Reference Y Get only −99,999.9999 to 99,999.9999 0 SY ---
11 Reference angle Get only −180 to 180 0 ST ---
12 Detection coordinate X Get only −99,999.9999 to 99,999.9999 0 RX ---
13 Detection coordinate Y Get only −99,999.9999 to 99,999.9999 0 RY ---
14 Count Get only 0 to 32 0 C Logged data
103
Output
parame-
ter
Reflect Set / Get
0: Yes
1: No 0 --- ---
120 Model
region
Rotation Set / Get 0: No
1: Yes
0 --- ---
121 Rotation angle upper
limit
Set / Get −180 to 180 180 --- ---
122 Rotation angle lower
limit
Set / Get −180 to 180 −180 --- ---
123 Mea-
sure-
ment
condi-
tions
Edge level (model) Set / Get 0 to 1024 20 --- ---
133 Candidate level Set / Get 0 to 100 50 --- ---
134 Detec-
tion point
coordi-
nate
Detection point X Set / Get 0 to 9999 0 --- ---
135 Detection point Y Set / Get 0 to 9999 0 --- ---
136
Mea-
sure-
ment
condition
Sort condition Set / Get
0: Ascending order of correlation
value,
1: Descending order of correlation
value,
2: Ascending order of position X,
3: Descending order of position X,
4: Ascending order of position Y,
5: Descending order of position Y
1 --- ---
138 Judge-
ment
condi-
tions
Judgement upper limit
for correlation
Set / Get 0 to 100 100 --- Judgement
condition
139 Judgement lower limit
for correlation
Set / Get 0 to 100 60 --- Judgement
condition
140 Judgement upper limit
for detection count
Set / Get 0 to 32 32 --- Judgement
condition
141 Judgement lower limit
for detection count
Set / Get 0 to 32 0 --- Judgement
condition
142 Judgement upper limit
for search coordinate X
Set / Get −99,999.9999 to 99,999.9999 99,999.9999 --- Judgement
condition
143 Judgement lower limit
for search coordinate X
Set / Get −
99,999.9999 to 99,999.9999 −99
,999.9999 --- Judgement
condition
144 Judgement upper limit
for search coordinate Y
Set / Get −99,999.9999 to 99,999.9999 99,999.9999 --- Judgement
condition
145 Judge-
ment
condi-
tions
Judgement lower limit
for search coordinate Y
Set / Get −99,999.9999 to 99,999.9999 −99,999.9999 --- Judgement
condition
146 Judgement upper limit
for search angle
Set / Get −180 to 180 180 --- Judgement
condition
147 Judgement lower limit
for search angle
Set / Get −180 to 180 −180 --- Judgement
condition
External
refer-
ence
number
Category Data name Set / Get Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
