Changing the Scene to Change the Line Process

368

FQ2-S/CH User’s Manual

Switching Scenes from an External Device

• Changing Scenes by Parallel Input Command

Vision Sensor FQ2-S/CH Series User's Manual for Communications Settings (Cat. No. Z338)

Section 2 Controlling Operation and Outputting Data with a Parallel Connection

• Changing Scenes by PLC Link Command

Vision Sensor FQ2-S/CH Series User's Manual for Communications Settings (Cat. No. Z338)

3-2 Controlling Operation and Outputting Data with PLC Link Communications

• Changing Scenes by EtherNet/IP Command

Vision Sensor FQ2-S/CH Series User's Manual for Communications Settings (Cat. No. Z338)

3-1 Controlling Operation and Outputting Data with EtherNet/IP Communications

• Changing Scenes by TCP No-protocol Command or a UDP No-protocol Command

Vision Sensor FQ2-S/CH Series User's Manual for Communications Settings (Cat. No. Z338)

3-4 Control and Output in No-protocol (TCP) / No-protocol (UDP)

• Changing Scenes by FINS/TCP No-protocol Command

Vision Sensor FQ2-S/CH Series User's Manual for Communications Settings (Cat. No. Z338)

3-5 Controlling Operation and Outputting Data with FINS/TCP No-protocol Commands

• Changing scenes by PROFINET command

Vision Sensor FQ2-S/CH Series User's Manual for Communications Settings (Cat. No. Z338)

3-3 Outputting Data and Controlling Operation through PROFINET

Setting the Startup Scene

(Setup Mode) − [Sensor settings] − [Startup settings]

The following items can be set.

Item Purpose Setting range

Startup mode

Select whether the startup scene

number is set manually.

OFF

(The scene number when the settings were saved

will be the startup scene number. The startup mode

is set to OFF in the Default settings.)

Startup scene

Set the scene number to use at

startup.

Standard models: 0 to 31

Single-function models: 0 to 8,

Default: 0
