Omron FQ2-S/CH Series User Manual

Specifications and Dimensions
546
FQ2-S/CH User’s Manual
9-3 Specifications and Dimensions
FQ2-S1
FQ2-S2
FQ2-S3 FQ2-S4
FQ2-CH
Sensor
Specifications
FQ2-S1/S2/S3 Series
Item Single-function
models
Standard mod-
els
High-resolution models
Model NPN FQ2-S10 FQ2-S20 FQ2-
S30-08
FQ2-
S30-08M
FQ2-S30-13 FQ2-S30-
13M
PNP FQ2-S15 FQ2-S25 FQ2-
S35-08
FQ2-
S35-08M
FQ2-S35-13 FQ2-S35-
13M
Field of view Refer to Table 1. Lens is select according to
the field of vision and installa-
tion distance. Refer to the
Optical Chart page.
Installation distance Refer to Table 1.
Main func-
tions
Inspection items Search, shape search II, sensitive search, area, color data, edge position, edge pitch, edge width, and
labeling
Number of
simultaneous
measurements
132
Position com-
pensation
Supported (360° Model position compensation, Edge position compensation, Linear correction)
Number of reg-
istered scenes*
1
832
Calibration Supported
input
Image process-
ing method
Real color Monochrome Real color Monochrome
Image filter High dynamic range (HDR), pre-processing (color gray filter (Sensors with Color Cameras only), weak
smoothing, strong smoothing, dilate, erosion, median, extract edges, extract horizontal edges, extract
vertical edges, enhance edges, and background suppression), polarizing filter (attachment), white bal-
ance (Sensors with Color Cameras only), and brightness correction
Image elements 1/3-inch color CMOS 1/2-inch color
CMOS
1/2-inch Mono-
chrome CMOS
1/2-inch color
CMOS
1/2-inch
Monochrome
CMOS
Shutter Built-in lighting lit: 1/250 to 1/50,000
Built-in lighting not lit: 1/1 to 1/50,000
Built-in lighting lit: 1/250 to 1/60,000
Built-in lighting not lit: 1/1 to 1/4,155
1/1 to 1/4,155
Processing res-
olution
752×480 928×828 1280×1024
Partial input
function
Supported horizontally only. Supported horizontally and vertically
Image display Zoom-in/Zoom-out/Fit Width/Rotate 180°
Lens mounts --- C-mounts
Lighting Lighting method Pulse ---
Lighting color White ---
Data log-
ging
Measurement
data
In Sensor: 1,000 items (If a Touch Finder is used, results can be saved up to the capacity of an SD
card.)
Images In Sensor: 20 images (If a Touch Finder is used, images can be saved up to the capacity of an SD card.)
Auxiliary function Statistical data, test measurement, I/O monitor, password function, simulation software, sensor error
history, calibration, math (arithmetic, calculation functions, trigonometric functions, and logic functions)
