Omron FQ2-S/CH Series User Manual

Specifications and Dimensions
FQ2-S/CH User’s Manual
547
Appendices
9
Measurement trigger External trigger (single or continuous)
Communications trigger (Ethernet TCP no-protocol, Ethernet UDP no-protocol, Ethernet FINS/TCP no-
protocol, PROFINET, EtherNet/IP, or PLC Link)
I/O specifi-
cations
Input signals 7 signals
• Single measurement input (TRIG)
• Control command input (IN0 to IN5)
Output signals 3 signals
• Control output (BUSY)
• Overall judgement output (OR)
• Error output (ERROR)
Note: The assignments of the three output signals (OUT0 to OUT2) can also be changed
to the following.
・READY
・RUN
・STG (Strobe trigger)
・OR (Item0 judgment) to OR31 (Item31 judgment)
・Exp.0 judgment to Exp.31 judgment
Ethernet specifi-
cations
100Base-TX/10Base-T
Communica-
tions
Ethernet TCP no-protocol, Ethernet UDP no-protocol,
Ethernet FINS/TCP no-protocol,
EtherNet/IP, or
PLC Link
PROFINET
I/O expansion --- --- Possible by connecting FQ-SDU1 Sensor Data Unit.11 inputs and
24 outputs
RS-232C --- --- Possible by connecting FQ-SDU2 Sensor Data Unit.
Input specifica-
tions
Refer to Table 2.
Output specifi-
cations
Connection
method
Special connector cables
Power supply and I/O: 1 cable
(FQ-WD)
Touch Finder and computer: 1
cable (FQ-WN)
Special connector cables
Power supply I/O and Sensor Data Units: 1 cable (FQ-WD and
FQ-WU)
Touch Finder and computer: 1 cable (FQ-WN)
Indications BUSY indicator (BUSY, green), Judgment result indicator (OR, orange), error indicator (ERROR, red),
Ethernet communications indicator (ETN, orange)
Note: The assignment of the BUSY indicator can be changed to a RUN indicator (display color: green).
Ratings Power supply
voltage
21.6 to 26.4 VDC (including ripple)
Insulation resis-
tance
Between all lead wires and case: 0.5 MΩ (at 250 V)
Current con-
sumption
2.4 A max. 0.3 A max.
Item Single-function
models
Standard mod-
els
High-resolution models
Model NPN FQ2-S10 FQ2-S20 FQ2-
S30-08
FQ2-
S30-08M
FQ2-S30-13 FQ2-S30-
13M
PNP FQ2-S15 FQ2-S25 FQ2-
S35-08
FQ2-
S35-08M
FQ2-S35-13 FQ2-S35-
13M

Omron FQ2-S/CH Series Specifications

General

Brand	Omron
Model	FQ2-S/CH Series
Category	Digital Camera
Language	English
