Inspecting with the Edge Width Inspection Item
FQ2-S/CH User’s Manual
285
4
Setting Up Inspections
Changing Edge Detection Conditions (Sensors with Monochrome Cameras Only)
You can change the measurement conditions for Sensors with Monochrome Cameras.
Change the [Density change] and [Measurement method] parameters.
p. 275
Reflect in Total Judgment
You can specify whether to reflect the judgment results of an inspection item in the overall judgment.
The Default is to reflect them.
[Inspect] − [Inspection] − [Add item.] − [Edge Width] − [Details] Tab Page − [Output parameter]
Unstable Edge Width Results (Sensors with Color Cameras)
If the measurement result is not stable, adjust the [Edge level], [Noise level], and [Set color.] parameters.
p. 276
Increasing Edge Width Processing Speed
Make the measurement region smaller to reduce the processing time.
Changing the measurement region: p. 227
