Omron FQ2-S/CH Series User Manual

External Reference Parameters
524
FQ2-S/CH User’s Manual
Search (FQ2-S1/S2/S3 series or FQ2-S4 series only)
External
refer-
ence
number
Category Data name Set / Get Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
0 Mea-
sure-
ment
result
Judgement Get only −2: No judgement (not measured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not performed error,
−14: Figure not registered error,
−15: Out of range error
−2 JG Logged data
5 Correlation Get only 0 to 100 0 CR[0] to
CR[31]
Logged data
6 Position X Get only −99,999.9999 to 99,999.9999 0 X[0] to
X[31]
Logged data
7 Position Y Get only −99,999.9999 to 99,999.9999 0 Y[0] to
Y[31]
Logged data
8 Angle Get only −180 to 180 0 TH[0] to
TH[31]
Logged data
9 Reference X Get only −99,999.9999 to 99,999.9999 0 SX ---
10 Reference Y Get only −99,999.9999 to 99,999.9999 0 SY ---
11 Reference angle Get only −180 to 180 0 ST ---
12 Detection coordinate X Get only −99,999.9999 to 99,999.9999 0 RX ---
13 Detection coordinate Y Get only −99,999.9999 to 99,999.9999 0 RY ---
14 Count Get only 0 to 32 0 C Logged data
103 Output
parame-
ter
Reflect Set / Get 0: Yes
1: No
0 --- ---
121 Model
region
Rotation Set / Get 0: Yes
1: No
0 --- ---
122 Rotation angle upper
limit
Set / Get −180 to 180 180 --- ---
123 Rotation angle lower
limit
Set / Get −180 to 180 −180 --- ---
126 Stability Set / Get 1 to 15 12 --- ---
127 Precision Set / Get 1 to 3 2 --- ---
132 Detec-
tion coor-
dinate
Detection point X Set / Get −99,999.9999 to 99,999.9999 0 --- ---
133 Detection point Y Set / Get −99,999.9999 to 99,999.9999 0 --- ---
134 Mea-
sure-
ment
condition
Sub-pixel Set / Get 0: Yes
1: No
0 --- ---
136 Judge-
ment
condi-
tions
Judgement upper limit
for search coordinate X
Set / Get −99,999.9999 to 99,999.9999
99,999.9999
--- Judgement
condition
137 Judgement lower limit
for search coordinate X
Set / Get −99,999.9999 to 99,999.9999
−99,999.9999
--- Judgement
condition
138 Judgement upper limit
for search coordinate Y
Set / Get −99,999.9999 to 99,999.9999
99,999.9999
--- Judgement
condition
139 Judgement lower limit
for search coordinate Y
Set / Get −99,999.9999 to 99,999.9999
−99,999.9999
--- Judgement
condition
140 Judgement upper limit
for search angle
Set / Get −180 to 180 180 --- Judgement
condition
