Inspecting with the Shape Search II Inspection Item
258
FQ2-S/CH User’s Manual
Measurement Data That Can Be Logged
The following values can be logged as measurement data.
* When logging data is output, the data is output in the order of the above table.
If more than one item is stored, results are output for each model.
7-6 Logging Measurement Data and Image Data: p. 392
Errors
Errors in Teaching
A teaching error message will appear if the contrast of the image within the model registration region is too low.
Select a region with a larger contrast between light and dark areas compared to the region that was registered
as the model and re-register it as the model.
Parameter Range of value Description
Judgement
0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
This is the measurement judgment results.
Correlation 0 to 100 This is the measured correlation.
Position X -99999.9999 to 99999.9999 This is the measurement position X.
Position Y -99999.9999 to 99999.99999 This is the measurement position Y.
Angle −180 to 180 This is the measurement angle.
Count 0 to 32 This is the number of models found.
