Calculations and Judgments Using Inspection Item Data
FQ2-S/CH User’s Manual
323
4
Setting Up Inspections
4-18 Calculations and Judgments Using Inspection Item Data
FQ2-S1
FQ2-S2
FQ2-S3 FQ2-S4
FQ2-CH
You can set inspection item judgment results and measurement data with the Calculation menu command to
use them in basic arithmetic operations and functions. The judgment results of the calculations are reflected in
the overall judgment.
Calculation
Use the Calculation menu command to set the calculation expressions and the judgment parameters for the
calculation results.
Expression
You can get up to 32 expressions. You can also combine expressions.
You can use the following values in calculations.
• Filter item and position compensation item data (measurement data, reference values, and judgment results)
• Inspection item data (measurement data, reference values, and judgment results)
• Constants
• Other calculation results
Judgment
Upper and lower limit values are used for the judgment of calculation results (D00 to D31). If within the upper
and lower limits, each calculation judgment result (J00 to J31) is OK. If all registered calculation results are
judged OK, the judgment result (JG) is OK.
If there is at least one NG, the judgment result (JG) is NG. The judgment result (JG) of calculation can be
reflected in the overall judgment.
(It is also possible to not reflect the judgment result in the output parameter(s) settings.)
