Omron FQ2-S/CH Series

Reading 2D Codes (DPM)
202
FQ2-S/CH User’s Manual
Setup Procedure for 2D-code (DPM)
Step 1 Select the Inspection Item
[Inspect] - [Modify]
1 Press an unused inspection item number
and press [Add item.].
2 Press [2D-code (DPM)].
4-3 Configuring Inspection Items: p. 138
Drag the arrow ( ) at the bottom of the menu to display all of
the inspection items.
Note
