External Reference Parameters
490
FQ2-S/CH User’s Manual
Edge Position Compensation
310 Logging
condi-
tions
Data logging switch for
entire unit
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
311 Data logging switch for
judgement
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
312 Data logging switch for
scroll X
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
313 Data logging switch for
scroll Y
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
315 Data logging switch for
position X
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
316 Data logging switch for
position Y
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
321 Data logging switch for
correlation
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
700 Display
settings
Position compensation
X display
Set / Get 0: Display
1: Do not display
0 --- ---
701 Position compensation
Y display
Set / Get 0: Display
1: Do not display
0 --- ---
702 Correlation display Set / Get 0: Display
1: Do not display
0 --- ---
703 Position X display Set / Get 0: Display,
1: Do not display
0 --- ---
704 Position Y display Set / Get 0: Display
1: Do not display
0 --- ---
External
reference
number
Category Data name Get / Set Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
0
Mea-
sure-
ment
result
Judgement Get only
−2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
−2 JG Logged data
5 Scroll X Get only −99,999.9999 to 99,999.9999 0 DX Logged data
6 Scroll Y Get only −99,999.9999 to 99,999.9999 0 DY Logged data
7 Edge position X Get only −99,999.9999 to 99,999.9999 0 X Logged data
8 Edge position Y Get only −99,999.9999 to 99,999.9999 0 Y Logged data
9 Standard position X Get only −99,999.9999 to 99,999.9999 0 SX Logged data
10 Standard position Y Get only −99,999.9999 to 99,999.9999 0 SY Logged data
103 Output
parame-
ter
Reflect Set / Get 0: Yes, 1: No 0 --- ---
External
reference
number
Category Data name
Set / Get
Data range Default Expression
text string
Logged data/
Judgement
parameter
