Inspecting with Color Data Inspection Item
298
FQ2-S/CH User’s Manual
Measurement Data That Can Be Used for External Outputs and Calculations
The following values can be used as measurement data and output to external devices via the Ethernet or
used in calculations.
4-18 Calculations and Judgments Using Inspection Item Data: p. 323
Expression
text string
Data name Description Data range
JG Judgement
−2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−10: Image error
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
−20: Other error
This is the judgment result.
AR R average 0 to 255 This is the average value of the R (red) compo-
nent.
AG G average 0 to 255 This is the average value of the G (green) com-
ponent.
AB B average 0 to 255 This is the average value of the B (blue) compo-
nent.
AD Color diff./dens. AV.
Color difference
0 to 442 (For Sensors with Color Cameras) This is the dif-
ference between the average color in the region
and the standard color.
0 to 255 (For Sensors with Monochrome Cameras) This
is the difference between the average density in
the region and the standard density.
DV
Clr. deviat. Color
deviation
0 to 221 (For Sensors with Color Cameras) This is the
deviation within the region.
0 to 217 (For Sensors with Monochrome Cameras) This
is the deviation within the region
