Inspecting with the Shape Search III Inspection Item
244
FQ2-S/CH User’s Manual
Editing the Model Regions and Measurement Region
Changing the Model Regions
This section describes how to edit the model regions.
You can edit the model region in the same way as for a search region.
Changing the Model Registration Region to a Shape Other Than a Rectangle: p. 225
If the model region is changed, perform teaching again. p. 232
Model registration region
Measurement region
(region that is searched for the model)
To Next Page
