Omron FQ2-S/CH Series

External Reference Parameters
FQ2-S/CH User’s Manual
477
Appendices
9
9-2 External Reference Parameters
FQ2-S1
FQ2-S2
FQ2-S3 FQ2-S4
FQ2-CH
Color Gray Filter (Color type only)
External
reference
number
Category Data name Set/Get Data range Default Expres-
sion text
string
Logged
data/
Judge-
ment
parameter
0 Measurement
result
Judgement Get only
−2: No judgement (not measured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
−2JG ---
120
Measurement
conditions
Source image Set / Get 0: Camera image
1: Previous image
1 --- ---
121 Setting method Set / Get 0: Filtering OFF, 1: Filtering ON 1 --- ---
122 Filter type Set / Get
Filter type
0: RGB
1: HSV
0 --- ---
123 Color filter type Set / Get
Color Filter Type
0: Red filter
1: Green filter
2: Blue filter
3: Cyan filter
4: Magenta filter
5: Yellow filter
6: Gray filter (R+G+B)
7: Gray filter (R+2G+B)
8: Gray filter (user-set)
0 --- ---
124 Color gray filter type Set / Get Color Gray Filter Type
0: High speed, 1: High precision
1 --- ---
125 RGB gain R Set / Get 0.0001 to 9.9999 0.3 --- ---
126 RGB gain G Set / Get 0.0001 to 9.9999 0.59 --- ---
127 RGB gain B Set / Get 0.0001 to 9.9999 0.11 --- ---
128 Standard hue Set / Get 0 to 359 0 --- ---
129 Hue range Set / Get 10 to 180 90 --- ---
130 Chroma upper limit Set / Get 0 to 255 255 --- ---
131 Chroma lower limit Set / Get 0 to 255 0 --- ---
