Omron FQ2-S/CH Series

Inspecting with the Edge Width Inspection Item
FQ2-S/CH User’s Manual
287
4
Setting Up Inspections
Errors
Errors in Teaching
A teaching error message will appear if the edge position cannot be detected when teaching. Perform the
following.
• If the color of the measurement object has changed from the specified color, set the color again and try teaching
again.
• If there is an edge and it cannot be detected, adjust the [Noise level] on the [Details] Tab Page and try teaching
again.
If an edge is not detected when teaching, 0 will be registered as the reference width.
Edge Not Found
The measured edge width will be 0. Perform the following:
• If a color was specified, make sure the color of the measurement object has not changed from the specified color.
• Set the color again if necessary.
• If there is an edge and it cannot be detected, make sure the [Edge level] parameter on the [Details] Tab Page is cor-
rect.
Edge level: p. 276
