External Reference Parameters
FQ2-S/CH User’s Manual
489
Appendices
9
Search Position Compensation
External
reference
number
Category Data name
Set / Get
Data range Default Expression
text string
Logged data/
Judgement
parameter
0Mea-
sure-
ment
result
Judgement Get only −2: No judgement (not mea-
sured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not performed
error,
−14: Figure not registered error,
−15: Out of range error
−2 JG Logged data
5Mea-
sure-
ment
result
Scroll X Get only −99,999.9999 to 99,999.9999 0 DX Logged data
6 Scroll Y Get only −99,999.9999 to 99,999.9999 0 DY Logged data
8 Position X Get only −99,999.9999 to 99,999.9999 0 X Logged data
9 Position Y Get only −99,999.9999 to 99,999.9999 0 Y Logged data
11 Reference X Get only −99,999.9999 to 99,999.9999 0 SX Logged data
12 Reference Y Get only −99,999.9999 to 99,999.9999 0 SY Logged data
14 Correlation Get only 0 to 100 0 CR Logged data
103
Output
parame-
ter
Reflect Set / Get
0: Yes
1: No 0 --- ---
120 Mea-
sure-
ment
condi-
tions
Position compensation
precision
Set / Get 0: None
1: Bilinear
0 --- ---
122 Position compensation
Set / Get 0: Camera image,
1: Previous image
1 --- ---
124 Model
region
Reference X Set / Get 0 to 99,999.9999 0 --- ---
125 Reference Y Set / Get 0 to 99,999.9999 0 --- ---
145 Detec-
tion coor-
dinate
Detection point X Set / Get 0 to 9,999 0 --- ---
146 Detection point Y Set / Get 0 to 9,999 0 --- ---
147 Mea-
sure-
ment
condi-
tions
Sub-pixel Set / Get 0: No, 1: Yes 0 --- ---
148 Candidate level Set / Get 0 to 100 70 --- ---
166 Judge-
ment
condi-
tions
Judgement upper limit
for correlation
Set / Get 0 to 100 100 --- Judgement
condition
167 Judgement lower limit
for correlation
Set / Get 0 to 100 60
