Omron FQ2-S/CH Series User Manual

External Reference Parameters
FQ2-S/CH User’s Manual
537
Appendices
9
Edge Pitch (FQ2-S1/S2/S3 series or FQ2-S4 series only)
External
refer-
ence
number
Category Data name Set / Get Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
0Mea-
sure-
ment
result
Judgement Get only −2: No judgement (not measured),
0: Judgement is OK,
−1: Judgement is NG
−13: Teaching not performed error,
−14: Figure not registered error,
−15: Out of range error
−2 JG Logged data
5 Edge pitch Get only 0 to 999 0 N Logged data
6 Average pitch Get only 0 to 99,999.9999 0 P Logged data
7 Maximum pitch Get only 0 to 99,999.9999 0 PH Logged data
8 Minimum pitch Get only 0 to 99,999.9999 0 PL Logged data
9 Average width Get only 0 to 99,999.9999 0 W Logged data
10 Maximum pitch Get only 0 to 99,999.9999 0 WH Logged data
11 Minimum pitch Get only 0 to 99,999.9999 0 WL Logged data
103 Output
parame-
ter
Reflect Set / Get 0: Yes
1: No
0 --- ---
120 Mea-
sure-
ment
condi-
tions
Edge color red Set / Get 0 to 255 255 --- ---
121 Edge color green Set / Get 0 to 255 255 --- ---
122 Edge color blue Set / Get 0 to 255 255 --- ---
127 Edge level Set / Get 0 to 100 50 --- ---
128 Noise level Set / Get 0 to 442 5 --- ---
130 Judge-
ment
condi-
tions
Edge pitch upper limit Set / Get 0 to 1,000 1,000 --- Judgement
condition
131 Edge pitch lower limit Set / Get 0 to 1,000 0 --- Judgement
condition
132 Average pitch upper
limit
Set / Get 0 to 99,999.9999 99,999.9
999
--- Judgement
condition
133 Average pitch lower
limit
Set / Get 0 to 99,999.9999 0 --- Judgement
condition
134 Pitch upper limit Set / Get 0 to 99,999.9999 99,999.9
999
--- Judgement
condition
135 Pitch lower limit Set / Get 0 to 99,999.9999 0 --- Judgement
condition
136 Average width upper
limit
Set / Get 0 to 99,999.9999 99,999.9
999
--- Judgement
condition
137 Average width lower
limit
Set / Get 0 to 99,999.9999 0 --- Judgement
condition
138 Width upper limit Set / Get 0 to 99,999.9999 99,999.9
999
--- Judgement
condition
139 Width lower limit Set / Get 0 to 99,999.9999 0 --- Judgement
condition
