Omron FQ2-S/CH Series

External Reference Parameters
478
FQ2-S/CH User’s Manual
Weak Smoothing
Strong Smoothing
Dilate
External
refer-
ence
number
Category Data name
Set / Get
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
0
Mea-
sure-
ment
result
Judgement Get only
−2: No judgement (not measured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not performed error,
−14: Figure not registered error,
−15: Out of range error
−2 JG ---
120 Mea-
sure-
ment
condi-
tions
Source image Set / Get 0: Camera image
1: Previous image
1 --- ---
121 Setting method Set / Get 0: Filtering OFF
1: Filtering ON
1 --- ---
External
reference
number
Category Data name
Set / Get
Data range Default Expression
text string
Logged data/
Judgement
parameter
0
Mea-
sure-
ment
result
Judgement Get only
−2: No judgement (not measured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not performed error,
−14: Figure not registered error,
−15: Out of range error
−2JG ---
120 Mea-
sure-
ment
condi-
tions
Source image Set / Get 0: Camera image,
1: Previous image
1 --- ---
121 Setting method Set / Get 0: Filtering OFF, 1: Filtering ON 1 --- ---
External
reference
number
Category Data name
Set / Get
Data range Default Expression
text string
Logged data/
Judgement
parameter
0
Mea-
sure-
ment
result
Judgement Get only
−2: No judgement (not measured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not performed error,
−14: Figure not registered error,
−15: Out of range error
−2JG ---
120 Mea-
sure-
ment
condi-
tions
Source image Set / Get 0: Camera image,
1: Previous image
1 --- ---
121 Setting method Set / Get 0: Filtering OFF, 1: Filtering ON 1 --- ---
