External Reference Parameters
480
FQ2-S/CH User’s Manual
Shape Search II (FQ2-S1/S2/S3 series or FQ2-S4 series only)
130 Mea-
sure-
ment
condi-
tions
B lower limit Set / Get 0 to 255 0 --- ---
131 B upper limit Set / Get 0 to 255 255 --- ---
132 Grayscale lower limit Set / Get 0 to 255 0 --- ---
133 Grayscale upper limit Set / Get 0 to 255 255 --- ---
External
refer-
ence
number
Category Data name
Set / Get
Data range Default Expression
text string
Logged data/
Judgement
parameter
0
Measure-
ment
result
Judgement
Get only
−2: No judgement
(not measured)
0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
−2 JG Logged
5 Correlation Get only 0 to 100 0 CR[0] to
CR[31]
Logged
6 Position X Get only −99,999.9999 to 99,999.9999 0 Y[0] to
Y[31]
Logged
7 Position Y Get only −99,999.9999 to 99,999.9999 0 --- Logged
8 Angle Get only -180 to 180 0 --- Logged
9 Reference X Get only −99,999.9999 to 99,999.9999 255 --- ---
10 Reference Y Get only −99,999.9999 to 99,999.9999 0 --- ---
11 Reference angle Get only -180 to 180 255 --- ---
12 Detection coordinate
X
Get only −99,999.9999 to 99,999.9999 0 --- ---
13 Detection coordinate
Y
Get only −99,999.9999 to 99,999.9999 255 --- ---
14 Count Get only 0 to 32 0 C ---
103 Output
parame-
ter
Reflect Set / Get 0: Yes
1: No
0 --- ---
120
Model
region
Rotation Set / Get 0: No
1: Yes
0 --- ---
121 Rotation angle upper
limit
Set / Get -180 to 180 180 --- ---
122 Rotation angle lower
limit
Set / Get -180 to 180 -180 --- ---
133 Mea-
sure-
ment
condi-
tions
Candidate level Set / Get 0 to 100 80 --- ---
External
reference
number
Category Data name
Set / Get
Data range Default Expression
text string
Logged data/
Judgement
parameter
