External Reference Parameters
FQ2-S/CH User’s Manual
539
Appendices
9
Area (FQ2-S1/S2/S3 series or FQ2-S4 series only)
External
reference
number
Category Data name Set / Get Data range Default Expres-
sion
text
string
Logged data/
Judgement
parameter
0 Mea-
sure-
ment
result
Judgement Get only −2: No judgement (not measured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not performed error,
−14: Figure not registered error,
−15: Out of range error
−2 JG ---
5 Mea-
sure-
ment
result
Area Get only 0 to 999,999,999.9999 0 AR ---
6 Gravity X Get only −99,999.9999 to 99,999.9999 0 X Logged data
7 Gravity Y Get only −99,999.9999 to 99,999.9999 0 Y Logged data
8 Reference area Get only 0 to 999,999,999 0 SA Logged data
9 Reference position X Get only −99,999.9999 to 99,999.9999 0 SX ---
10 Reference position Y Get only −99,999.9999 to 99,999.9999 0 SY ---
11 Area deviation Get only −999,999,999.9999 to
999,999,999.9999
0 DF Logged data
103 Output
parame-
ter
Reflect Set / Get 0: Yes
1: No
0 --- ---
127 Mea-
sure-
ment
condi-
tions
Background color Set / Get 0: Black
1: White
2: Red
3: Green
4: Blue
0 --- ---
128 Fill profile Set / Get 0: No
1: Fill outline,
2: Filling up holes
0 --- ---
129 Area color inversion Set / Get 0: None
1: Enabled
The binary inversion is displayed for a
Monochrome Camera.
0 --- ---
135 Judge-
ment
Judgement upper limit
for area
Set / Get 0 to 999,999,999.9999
999,999,999
.9999
--- ---
136 Judgement lower limit
for area
Set / Get 0 to 999,999,999.9999 0 --- ---
137 Judgement upper limit
for gravity X
Set / Get −99,999.9999 to 99,999.9999
99,999.9999
--- ---
138 Judgement lower limit
for gravity X
Set / Get −99,999.9999 to 99,999.9999
−
99,999.9999
--- ---
139 Judgement upper limit
for gravity Y
Set / Get −99,999.9999 to 99,999.9999
99,999.9999
--- ---
140 Judgement lower limit
for gravity Y
Set / Get −99,999.9999 to 99,999.9999
−
99,999.9999
--- ---
141 Judgement upper limit
for binary threshold
Set / Get 0 to 255 255 --- ---
142 Judgement lower limit
for binary threshold
Set / Get 0 to 255 128 --- ---
