External Reference Parameters
FQ2-S/CH User’s Manual
515
Appendices
9
*1 Use the ITEMDATA2 command to set and/or acquire a text string.
2D-code (FQ2-S4 series only)
410 Logging
condi-
tions
Data logging switch for
unit
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
411 Data logging switch for
judgement
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
412 Data logging switch for
number of characters
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
500 Display
setting
Number of characters
display
Set / Get 0: OFF
1: ON
0 --- ---
501 Character display Set / Get 0: ON
1: OFF
0 --- ---
External
refer-
ence
number
Category Data name Set / Get Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
0Mea-
sure-
ment
result
Judgement Get only −2: Not measured,
0: Judgement is OK,
1: Judgement is NG,
−16: Measurement timeout
error
−2 JG Logged data
5 Index No. Get only −2: No verification pattern,
or reading error
−1: Verification is NG,
0 to 31: Master data No.
−2IN ---
6 Num. of characters Get only 0 to 1024 0 N Logged data
7
*1
Characters Get only 32 characters max. 0 --- ---
50 Overall quality Get only 0 to 4 0 GD0 Logged data
51 Decode Get only 0 to 4 0 GD1 Logged data
52 Cell Contrast Get only 0 to 4 0 GD2 Logged data
53 Cell Modulation Get only 0 to 4 0 GD3 Logged data
54 Fixed pattern damage Get only 0 to 4 0 GD4 Logged data
55 Axial nonuniformity Get only 0 to 4 0 GD5 Logged data
56 Grid nonuniformity Get only 0 to 4 0 GD6 Logged data
57 Unused err. Corr. Get only 0 to 4 0 GD7 Logged data
58 Print scale Get only 0 to 4 0 GD8 Logged data
59 Print Scale X Get only 0 to 4 0 GD9 Logged data
60 Print Scale Y Get only 0 to 4 0 GD10 Logged data
103 Output
parame-
ter
Reflect Set / Get 0: Yes, 1: No 0 --- ---
External
refer-
ence
number
Category Data name Set / Get Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
