Omron FQ2-S/CH Series User Manual

External Reference Parameters
526
FQ2-S/CH User’s Manual
Sensitive Search (FQ2-S1/S2/S3 series or FQ2-S4 series only)
700 Display
settings
Correlation display Set / Get 0: Display
1: Do not display
0 --- ---
701 Position X display Set / Get 0: Display
1: Do not display
0 --- ---
702 Position Y display Set / Get 0: Display
1: Do not display
0 --- ---
703 Measurement angle
display
Set / Get 0: Display
1: Do not display
0 --- ---
704 Count display Set / Get 0: Display
1: Do not display
0 --- ---
800 Position X display pat-
tern
Set / Get 0: Absolute value
1: Relative value
0 --- ---
801 Position Y display pat-
tern
Set / Get 0: Absolute value
1: Relative value
0 --- ---
802 Measured angle dis-
play pattern
Set / Get 0: Absolute value
1: Relative value
0 --- ---
External
refer-
ence
number
Category Data name Set / Get Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
0 Mea-
sure-
ment
result
Judgement Get only −2: No judgement (not mea-
sured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not performed
error,
−14: Figure not registered error,
−15: Out of range error
−2 JG Logged data
5 Correlation Get only 0 to 100 0 CR Logged data
6 Deviation Get only Color Camera:
0.000 to 219.9705
Monochrome Camera:
0.000 to 127.000
0 DV Logged data
7 Measurement position
X (search center posi-
tion)
Get only −99,999.9999 to 99,999.9999 0 X Logged data
8 Measurement position
Y (search center posi-
tion)
Get only −99,999.9999 to 99,999.9999 0 Y Logged data
9 Angle Get only −180 to 180 0 TH Logged data
10 Mea-
sure-
ment
result
Detection X Get only −99,999.9999 to 99,999.9999 0 RX Logged data
11 Detection Y Get only −99,999.9999 to 99,999.9999 0 RY Logged data
12 Reference position X Get only −99,999.9999 to 99,999.9999 0 SX Logged data
13 Reference position Y Get only −99,999.9999 to 99,999.9999 0 SY Logged data
14 Reference angle Get only −180 to 180 0 ST Logged data
15 NG sub-region Get only 0 to 100 0 CT Logged data
16 Sub-region number Get only 0 to 99 0 AN Logged data
17 Sub-region number (X) Get only 0 to 9 0 ANX Logged data
External
refer-
ence
number
Category Data name Set / Get Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
