Omron FQ2-S/CH Series User Manual

External Reference Parameters
FQ2-S/CH User’s Manual
525
Appendices
9
141 Judge-
ment
condi-
tions
Judgement lower limit
for search angle
Set / Get −180 to 180 −180 --- Judgement
condition
142 Judgement upper limit
for correlation
Set / Get 0 to 100 100 --- Judgement
condition
143 Judgement lower limit
for correlation
Set / Get 0 to 100 60 --- Judgement
condition
145 Search candidate level Set / Get 0 to 100 70 --- ---
146 Mea-
sure-
ment
condi-
tions
Sort condition Set / Get For Multiple Searches
0: Ascending order of correlation
value,
1: Descending order of correlation
value,
2: Ascending order of position X,
3: Descending order of position X,
4: Ascending order of position Y,
5: Descending order of position Y
1 --- ---
148 Judge-
ment
condi-
tions
Judgement upper limit
for detection count
Set / Get 0 to 32 32 --- Judgement
condition
149 Judgement lower limit
for detection count
Set / Get 0 to 32 0 --- Judgement
condition
150 Mea-
sure-
ment
condi-
tions
Multiple output Set / Get 0: No, 1: Yes 0 --- ---
152 Extraction condition, X
upper limit
Set / Get −99,999.9999 to 99,999.9999 99,999.9999 --- ---
153 Extraction condition, X
lower limit
Set / Get −99,999.9999 to 99,999.9999 −
99,999.9999
--- ---
154 Extraction condition, Y
upper limit
Set / Get −99,999.9999 to 99,999.9999 99,999.9999 --- ---
155 Extraction condition, Y
lower limit
Set / Get −99,999.9999 to 99,999.9999 −
99,999.9999
--- ---
160 Detection count Set / Get 1 to 32 32 --- ---
300 Logging
condi-
tions
Number of data log
records
Set / Get 1 to 32 32 --- ---
310 Data logging switch for
entire unit
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
311 Data logging switch for
judgement
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
312 Data logging switch for
correlation
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
313 Logging
condi-
tions
Data logging switch for
position X
S
et / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
314 Data logging switch for
position Y
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
315 Data logging switch for
measurement angle
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
321 Data logging switch for
detection count
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
External
refer-
ence
number
Category Data name Set / Get Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
