External Reference Parameters
536
FQ2-S/CH User’s Manual
Edge Width (FQ2-S1/S2/S3 series or FQ2-S4 series only)
External
refer-
ence
number
Category Data name Set / Get Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
0Mea-
sure-
ment
result
Judgement Get only −2: No judgement (not measured),
0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
−2JG ---
5 Edge width Get only 0 to 99,999.9999 0 W Logged data
6 Reference edge width Get only 0 to 99,999.9999 0 SW Logged data
7 Difference in edge
width
Get only 0 to 99,999.9999 0 DF Logged data
103 Output
parame-
ter
Reflect Set / Get 0: Yes
1: No
0 --- ---
120 Mea-
sure-
ment
condi-
tions
Edge level specification
method
Set / Get 0:%
1: Absolute value
0 --- ---
121 Set color Set color Set / Get Edge color specification
0: Not specified,
1: Specified
0 --- ---
122 Mea-
sure-
ment
condi-
tions
Measurement method Set / Get 0: Projection
1: Differentiation
0 --- ---
131 Edge color red Set / Get 0 to 255 255 --- ---
132 Edge color green Set / Get 0 to 255 255 --- ---
133 Edge color blue Set / Get 0 to 255 255 --- ---
137 Edge level Set / Get 0 to 100 50 --- ---
138 Edge level absolute
value
Set / Get 0 to 442 20 --- ---
139 Noise level Set / Get 5 to 442 5 --- ---
142 Density change Set / Get 0: Light to Dark
1: Dark to Light
0 --- ---
143 Edge level absolute
value (Monochrome
Cameras)
Set / Get 0 to 255 20 --- ---
190 Judge-
ment
condi-
tions
Edge width upper limit Set / Get −99,999.9999 to 99,999.9999 99,999.9
999
--- Judgement
condition
191 Edge width lower limit Set / Get −99,999.9999 to 99,999.9999 0
310 Logging
condi-
tions
Data logging switch for
entire unit
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
311 Data logging switch for
judgement
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
312
Data logging switch
for edge width
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
700 Display
settings
Edge width display Setting/
Acquisition
0: Display
1: Do not display
0 --- ---
800 Wedge width display
pattern
Setting/
Acquisition
0: Absolute value
1: Relative value
2: Percentage
0 --- ---
