Omron FQ2-S/CH Series User Manual

Inspecting with the Edge Position Inspection Item
280
FQ2-S/CH User’s Manual
Measurement Data That Can Be Used for External Outputs and Calculations
The following values can be used as measurement data and output to external devices via the Ethernet or
used in calculations.
4-18 Calculations and Judgments Using Inspection Item Data: p. 323
Expression
text string
Data name Description Data range
JG Judgement
−2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
This is the judgment result.
XPosition X −99999.9999to 99999.9999 This is the X coordinate of the measured
edge position.
YPosition Y −99999.9999 to 99999.9999 This is the Y coordinate of the measured
edge position.
SX Ref. position X
(reference position X)
−99999.9999 to 99999.9999 This is the X coordinate of the edge position
when a range is set.
SY Ref. position Y
(reference position Y)
−99999.9999 to 99999.9999 This is the Y coordinate of the edge position
when a range is set.
DF D. position
(difference in position)
−99999.9999 to 99999.9999 This is the offset from the measured refer-
ence position.
