Omron FQ2-S/CH Series

Inspecting with the Shape Search II Inspection Item
248
FQ2-S/CH User’s Manual
Setup Procedure for the Shape Search II Inspection Item
Step 1 Selecting the Inspection Item
[Inspect] − [Inspection]
1 Press an unused inspection item number
and press [Add item.].
2 Press [Shape Search II].
Registering inspection items: p. 138
Drag the arrow at the bottom of the menu upward to display all of the inspection items.
Note
