Omron FQ2-S/CH Series User Manual

External Reference Parameters
FQ2-S/CH User’s Manual
519
Appendices
9
2D Codes (DPM) (FQ2-S4 series only)
External
refer-
ence
number
Category Data name Set / Get Data range Default Expres-
sion text
string
Logged
0 Mea-
sure-
ment
result
Judgment Get only
-2: No judgment (not
inspected)
0: Judgment result OK
-1: Judgment result NG
-16: Inspection timeout error
-2 JG
Logged
5 Num. of char. Get only 0 to 1024 0 N Logged
6
*1
Characters Get only Text string --- --- ---
8 Cell Recog. Rate Get only 0 to 100 0 E Logged
9 Contrast Get only 0 to 100 0 C Logged
10 Focus Get only 0 to 100 0 F ---
17 Index number Get only -2: No verification pattern
or reading error
-1: Verification is NG
0 to 31: Master data No.
−2IN
---
50 Overall quality Get only 0 to 4 0 GDA0 Logged
51 Decode Get only 0 to 4 0 GDA1 Logged
52 Cell Contrast Get only 0 to 4 0 GDA2 Logged
53 Cell Modulation Get only 0 to 4 0 GDA3 Logged
54 Fixed pattern damage Get only 0 to 4 0 GDA4 Logged
55 Axial nonuniformity Get only 0 to 4 0 GDA5 Logged
56 Grid nonuniformity Get only 0 to 4 0 GDA6 Logged
57 Unused err. Corr. Get only 0 to 4 0 GDA7 Logged
103 Output
parame-
ter
Reflect Set / Get 0: Yes, 1: No 0 --- ---
