Inspecting with the Sensitive Search Inspection Item
FQ2-S/CH User’s Manual
263
4
Setting Up Inspections
Reflect in Total Judgment
You can specify whether to reflect the judgment results of an inspection item in the overall judgment.
The Default is to reflect them.
[Inspect] − [Inspection] − [Add item.] − [Sensitive Search] − [Details] Tab Page −
[Output parameter]
Parameter Setting Description
Correlation
Range: 0 to 100
Default: Lower: 60, Upper: 100
Set the correlation range that is to be judged as OK. If
the correlation in the measurement results is 0, the
judgment will be NG regardless of the setting of the
lower limit.
Position X
Range: −99,999.9999 to 99,999.9999
Default: Lower: −99,999.9999
Upper: 99,999.9999
Set the range of movement in the X direction that is to
be judged as OK.
Position Y
Range: −99,999.9999 to 99,999.9999
Default: Lower: −99,999.9999
Upper: 99,999.9999
Set the range of movement in the Y direction that is to
be judged as OK.
Angle
Range: −180 to 180
Default: Lower: −180
Upper: 180
Set the angle range that is to be judged as OK.
Density deviation
Color image
Range: 0 to 221
Default: Lower: 0
Upper: 221
Monochrome image
Range: 0 to 127
Default: Lower: 0
Upper: 127
Set the density difference range that is to be judged as
OK.
The value will increase for larger percentages of areas
with no pattern. This parameter is valid when setting a
plain inspection area for a divided model.
• You can change the output form for each measurement value to one of the following settings.
Press [
] − [Result type] on the right of the display.
Absolute value (Default): The measured coordinates are output as absolute values.
Relative value: The difference from the reference value is output.
