Omron FQ2-S/CH Series User Manual

External Reference Parameters
540
FQ2-S/CH User’s Manual
143 Mea-
sure-
ment
condi-
tions
Binary image display Set / Get (Monochrome Cameras)
0: No binary image display,
1: Binary image display
1 --- ---
144 Image type Set / Get 0: Measurement image,
1: Color extraction image,
2: Selected color image,
3: Binary image after extraction
1 --- ---
145 Enable/disable multi-
ple selection
Set / Get 0: Enabled,
1: Disabled
1 --- ---
160+N×10
(N=0 to 3)
Set color Registered color usage
flag N
Set / Get 0: Not used
1: Used
1(N=0),
0(N=1 to
3)
--- ---
161+N×10
(N=0 to 3)
Registered color OR/
NOT flag N
Set / Get 0: OR, 1: NOT 0 --- ---
162+N×10
(N=0 to 3)
Registered color maxi-
mum hue N
Set / Get 0 to 359 359 --- ---
163+N×10
(N=0 to 3)
Registered color mini-
mum hue N
Set / Get 0 to 359 0 --- ---
164+N×10
(N=0 to 3)
Registered color maxi-
mum saturation N
Set / Get 0 to 255 255 --- ---
165+N×10
(N=0 to 3)
Registered color mini-
mum saturation N
Set / Get 0 to 255 0 --- ---
166+N×10
(N=0 to 3)
Registered color maxi-
mum brightness N
Set / Get 0 to 255 255 --- ---
167+N×10
(N=0 to 3)
Set color Registered color mini-
mum brightness N
Set / Get 0 to 255 0 --- ---
310 Logging
condi-
tions
Data logging switch for
entire unit
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
311 Data logging switch for
judgement
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
312 Data logging switch for
area
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
313 Data logging switch for
gravity X
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
314 Data logging switch for
gr
avity Y
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
700 Display
settings
Area display Set / Get 0: Display area
1: Do not display area
0 --- ---
701 Gravity X display Set / Get 0: Display gravity X
1: Do not display gravity X
0 --- ---
702 Gravity Y display Set / Get 0: Display gravity Y
1: Do not display gravity Y
0 --- ---
800 Area display pattern Set / Get 0: Absolute value
1: Relative value
2: Percentage
0 --- ---
801 Gravity X display pat-
tern
Set / Get 0: Absolute value
1: Relative value
0 --- ---
802 Gravity Y display pat-
tern
Set / Get 0: Absolute value
1: Relative value
0 --- ---
External
reference
number
Category Data name Set / Get Data range Default Expres-
sion
text
string
Logged data/
Judgement
parameter
