Omron FQ2-S/CH Series

External Reference Parameters
FQ2-S/CH User’s Manual
545
Appendices
9
602 Judge-
ment
Judgement upper limit
for number of labels
Set / Get 1 to 100 100 --- ---
603 Judgement lower limit
for number of labels
Set / Get 1 to 100 0 --- ---
612 Judgement upper limit
for label area
Set / Get 0 to 999,999,999.9999
999,999,999
.9999
--- ---
613 Judgement lower limit
for label area
Set / Get 0 to 999,999,999.9999 0 --- ---
622 Judgement upper limit
for area
Set / Get 0 to 999,999,999.9999
999,999,999
.9999
--- ---
623 Judgement lower limit
for area
Set / Get 0 to 999,999,999.9999 0 --- ---
632 Judgement upper limit
for gravity X
Set / Get −99,999.9999 to 99,999.9999
99,999.9999
--- ---
633 Judgement lower limit
for gravity X
Set / Get −99,999.9999 to 99,999.9999
−
99,999.9999
--- ---
642 Judgement upper limit
for gravity Y
Set / Get −99,999.9999 to 99,999.9999
99,999.9999
--- ---
643 Judgement lower limit
for gravity Y
Set / Get −99,999.9999 to 99,999.9999
−
99,999.9999
--- ---
652 Judgement upper limit
for master angle
Set / Get −180 to 180 180 --- ---
653 Judgement lower limit
for master angle
Set / Get −180 to 180 −180 --- ---
700 Display
settings
Number of labels dis-
play
Set / Get 0: ON
1: OFF
0 --- ---
701 Total label area display Set / Get 0: ON
1: OFF
0 --- ---
702 Area display Set / Get 0: ON
1: OFF
1 --- ---
703 Gravity X display Set / Get 0: ON
1: OFF
1 --- ---
704 Gravity Y display Set / Get 0: ON
1: OFF
1 --- ---
705 Master angle display Set / Get 0: ON
1: OFF
1 --- ---
External
refer-
ence
number
Category Data name Set / Get Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
