External Reference Parameters
530
FQ2-S/CH User’s Manual
133 Mea-
sure-
ment
condi-
tions
Candidate level Set / Get 0 to 100 80 --- ---
134 Detec-
tion point
coordi-
nate
Detection point X Set / Get 0 to 9999 0 --- ---
135 Detection point Y Set / Get 0 to 9999 0 --- ---
136 Mea-
sure-
ment
condition
Sort condition Set / Get 0: Ascending order of correlation
value,
1: Descending order of correla-
tion value,
2: Ascending order of position X,
3: Descending order of position
X,
4: Ascending order of position Y,
5: Descending order of position Y
1 --- ---
138 Judge-
ment
condi-
tions
Judgement upper limit
for correlation
Set / Get 0 to 100 100 --- Judgement
condition
139 Judgement lower limit
for correlation
Set / Get 0 to 100 60 --- Judgement
condition
140 Judgement upper limit
for detection count
Set / Get 0 to 32 32 --- Judgement
condition
141 Judgement lower limit
for detection count
Set / Get 0 to 32 0 --- Judgement
condition
142 Judgement upper limit
for search coordinate X
Set / Get −99,999.9999 to 99,999.9999 99,999.9999 --- Judgement
condition
143 Judgement lower limit
for search coordinate X
Set / Get −99,999.9999 to 99,999.9999 −99,999.9999 --- Judgement
condition
144 Judgement upper limit
for search coordinate Y
Set / Get −99,999.9999 to 99,999.9999 99,999.9999 --- Judgement
condition
145 Judge-
ment
condi-
tions
Judgement lower limit
for search coordinate Y
Set / Get −99,999.9999 to 99,999.9999 −99,999.9999 --- Judgement
condition
146 Judgement upper limit
for search angle
Set / Get −180 to 180 180 --- Judgement
condition
147 Judgement lower limit
for search angle
Set / Get −180 to 180 −180 --- Judgement
condition
152 Mea-
sure-
ment
condi-
tions
Extraction condition, X
upper limit
Set / Get −99,999.9999 to 99,999.9999 99,999.9999 --- Judgement
condition
153 Extraction condition, X
lower limit
Se
t / Get −99,999.9999 to 99,999.9999 −99,999.9999 --- Judgement
condition
154 Extraction condition, Y
upper limit
Set / Get −99,999.9999 to 99,999.9999 99,999.9999 --- Judgement
condition
155 Extraction condition, Y
lower limit
Set / Get −99,999.9999 to 99,999.9999 −99,999.9999 --- Judgement
condition
161 Detection count Set / Get 1 to 32 32 --- ---
170 Model mode Set / Get 0: Fast
1: Stable
0 --- ---
300 Logging
condi-
tions
Number of data log
records upper limit
Set / Get 1 to 32 32 --- ---
310 Data logging switch for
entire unit
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
311 Data logging switch for
judgement
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
External
refer-
ence
number
Category Data name Set / Get Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
