External Reference Parameters
500
FQ2-S/CH User’s Manual
187 Judge-
ment
condi-
tions
Edge position Y upper limit
1
Set / Get −99,999.9999 to 99,999.9999
99,999.99
99
--- Judgement
condition
188 Edge position Y lower limit
1
Set / Get −99,999.9999 to 99,999.9999
−
99,999.99
99
--- Judgement
condition
190 Edge angle upper limit Set / Get −180 to 180 180 --- Judgement
condition
191 Edge angle lower limit Set / Get −180 to 180 −180 --- Judgement
condition
310 Logging
condi-
tions
Data logging switch for
entire unit
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
311 Data logging switch for
judgement
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
312
Data logging switch
for position compensation
TH
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
313
Data logging switch
for detected edge position
X0
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
314
Data logging switch
for detected edge position
Y0
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
315
Data logging switch
for detected edge position
X1
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
316 Logging
condi-
tions
Data logging switch
for detected edge position
Y1
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
317
Data logging switch
for detected edge angle
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
700 Display
settings
Position compensation
theta display
Set / Get 0: ON
1: OFF
0 --- ---
701 Detected edge angle dis-
play
Set / Get 0: ON
1: OFF
0 --- ---
702 Display
settings
Detected edge position X0
display
Set / Get 0: ON
1: OFF
0 --- ---
703 Detected edge position Y0
display
Set / Get 0: ON
1: OFF
0 --- ---
704 Detected edge position X1
display
Set / Get 0: ON
1: OFF
0 --- ---
705 Detected edge position Y1
display
Set / Get 0: ON
1: OFF
0 --- ---
Exter-
nal ref-
erence
number
Category Data name Set / Get Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
To Next Page
