Omron FQ2-S/CH Series User Manual

External Reference Parameters
FQ2-S/CH User’s Manual
499
Appendices
9
120
Mea-
sure-
ment
condi-
tions
Position compensation pre-
cision
Set / Get 0: None, 1: Bilinear 0 --- ---
122 Position compensation
Set / Get 0: Camera image,
1: Previous image
1 --- ---
140 Edge color specification 0 Set / Get 0: No edge color specification,
1: Edge color specification
0 --- ---
141 Edge color R0 Set / Get 0 to 255 255 --- ---
142 Edge color G0 Set / Get 0 to 255 255 --- ---
143 Edge color B0 Set / Get 0 to 255 255 --- ---
147 Density change 0 Set / Get 0: Color IN, 1: Color OUT 0 --- ---
149 Edge level 0 Set / Get 0 to 100 50 --- ---
150 Noise level 0 Set / Get 0 to 442 5 --- ---
153 Monochrome density
change 0
Set / Get (Monochrome Cameras)
0: Light to Dark, 1: Dark to Light
0 --- ---
154 Edge level absolute value Set / Get 0 to 442 20 --- ---
155 Edge level specification
method
Set / Get 0:%
1: Absolute value
0 --- ---
157 Measurement method 0 Set / Get (Monochrome Cameras)
0: Projection
1: Differentiation
0 --- ---
158 Edge level absolute value
(Monochrome Cameras)
Set / Get 0 to 255 20 --- ---
160 Edge color specification 0 Set / Get 0: No edge color specification,
1: Edge color specification
0 --- ---
161 Edge color R1 Set / Get 0 to 255 255 --- ---
162 Edge color G1 Set / Get 0 to 255 255 --- ---
163 Edge color B1 Set / Get 0 to 255 255 --- ---
167 Density change 1 Set / Get 0: Color IN, 1: Color OUT 0 --- ---
169 Edge level 1 Set / Get 0 to 100 50 --- ---
170 Noise level 1 Set / Get 0 to 442 5 --- ---
173 Monochrome density
change 1
Set / Get (Monochrome Cameras)
0: Light to Dark
1: Dark to Light
0 --- ---
177 Measurement method 1 Set / Get (Monochrome Cameras)
0: Projection
1: Differentiation
0 --- ---
180 Judge-
ment
condi-
tions
Edge position X upper limit
0
Set / Get −99,999.9999 to 99,999.9999
99,999.99
99
--- Judgement
condition
181 Edge position X lower limit
0
Set / Get −99,999.9999 to 99,999.9999
−
99,999.99
99
--- Judgement
condition
182 Edge position Y upper limit
0
Set / Get −99,999.9999 to 99,999.9999
99,999.99
99
--- Judgement
condition
183 Edge position Y lower limit
0
Set / Get −99,999.9999 to 99,999.9999
−
99,999.99
99
--- Judgement
condition
185 Edge position X upper limit
1
Set / Get −99,999.9999 to 99,999.9999
99,999.99
99
--- Judgement
condition
186 Edge position X lower limit
1
Set / Get −99,999.9999 to 99,999.9999
−
99,999.99
99
--- Judgement
condition
Exter-
nal ref-
erence
number
Category Data name Set / Get Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
