Omron FQ2-S/CH Series User Manual

Menu Tables
FQ2-S/CH User’s Manual
467
Appendices
9
Calibration*
2
(Reference sampling)
Model region
Used to edit the model regions.
The procedure is the same as for setting
the model region for a Search inspection
item.
---
Calibra-
tion data
p. 374
Insp. region
Changes the size and position of the mea-
surement region. ---
Calibra-
tion data
Actual coord.
Sets the Camera coordinates and the
actual coordinates.
Point coordinate: 0 to 9999
Actual coordinate: 0 to 99999.9999
Calibra-
tion data
(Reference sampling)
Generate parameters
Used to create calibration parameters. ---
Calibra-
tion data
p. 374
(Parameter)
Coordi-
nate
Sets the positive direction when specifying
coordinates.
Righthand
Lefthand
(Default)
Calibra-
tion data
p. 377
Origin Select the location of the origin of the
coordinate system.
Lowerleft
Upperleft (Default)
Center
Calibra-
tion data
Magnifica-
tion
Set the actual dimension that corresponds
to one pixel.
0.0001 to 9.9999
(
Default :1.0000)
Calibra-
tion data
Clear Clears the parameter settings for the cali-
bration data.
--- --- ---
Copy Copies the calibration data. --- --- ---
Rename Changes the name of the calibration data. 15 alphanumeric characters max. Calibra-
tion data
---
Model dictionary*
2
Dictionary data 0 to 31
[MENU]
Modify Used to edit the dictionary data in the
model dictionary for character recognition
using custom characters.
---
Dictionary
data
p. 175
Rename Changes the name of dictionary data. 15 characters max. Dictionary
data
Copy Copies dictionary data. --- ---
Clear Clears the settings of dictionary data. --- ---
Save to file
Setting
Scene data Saves scene data with an SCN file name
extension.
--- --- p. 406
Scene group data Saves all scene data with an SGP file
name extension.
Calibration data Saves calibration data with an CLB file
name extension.
Calibration group
data
Saves calibration group data with an CGP
file name extension.
Dictionary data*
2
Saves dictionary data with a DIC file name
extension.
All dictionary data*
2
Saves all dictionary data with a DGP file
name extension.
Code data*
2
Saves all dictionary data with a DGP file
name extension.
Sensor system data Saves system data with csv file name
extension.
Menu command Description Setting range Data
