Checking the Trend of Measurement Results with Graphs
FQ2-S/CH User’s Manual
359
6
Operation
Arranging the Trend Monitor Display
The display range for the vertical axis and display conditions for the horizontal axis can be changed.
To change the display range of the vertical axis, [Auto display] must be set to OFF.
• Disabling Automatic Adjustment of the Display Range (Default: ON)
1 Press [ ] − [Auto display] on the right of the trend monitor.
2 Press [OFF].
• Changing the Display Range of the Vertical Axis
1 Press [ ] − [Display range] on the right of the trend monitor.
2 Set the minimum and maximum values of the measurement values.
• Changing the Number of Values That Are Displayed
1 Press [ ] − [Number of data] on the right of the trend monitor.
2 Select the number of values from 200, 400, and 1,000.
You can display only one parameter in the Trend Monitor. You cannot display multiple parameters at the same
time.
• Trend monitor data is held until the power supply is turned OFF.
•
You can select whether to display all data on the trend monitor or only data for which the overall judgement is NG.
Logging settings are applied to the trend monitor as well.
However, they are not applied to trend monitor when it is displayed in Setup Mode.
Check recent measurement trends (recent results logging): p. 401
