Omron FQ2-S/CH Series

External Reference Parameters
484
FQ2-S/CH User’s Manual
161
Judge-
ment
condi-
tions
Judgement lower limit
for search coordinate X Set / Get −99,999.9999 to 99,999.9999
−
99,999.9999
---
Judgement
condition
162
Judgement upper limit
for search coordinate Y Set / Get −99,999.9999 to 99,999.9999
99,999.9999
---
Judgement
condition
163
Judgement lower limit
for search coordinate Y Set / Get −99,999.9999 to 99,999.9999
−
99,999.9999
---
Judgement
condition
164 Judgement upper limit
for search angle
Set / Get −180 to 180 180 --- Judgement
condition
165 Judgement lower limit
for search angle
Set / Get −180 to 180 −180 --- Judgement
condition
166 Judgement upper limit
for correlation
Set / Get 0 to 100 100 --- Judgement
condition
167 Judgement lower limit
for correlation
Set / Get 0 to 100 60 --- Judgement
condition
168 Position compensation
X upper limit
Set / Get −99,999.9999 to 99,999.9999
99,999.9999
--- Judgement
condition
169 Position compensation
X lower limit
Set / Get −99,999.9999 to 99,999.9999
−
99,999.9999
--- Judgement
condition
170 Position compensation
Y upper limit
Set / Get −99,999.9999 to 99,999.9999
99,999.9999
--- Judgement
condition
171 Position compensation
Y lower limit
Set / Get −99,999.9999 to 99,999.9999
−
99,999.9999
--- Judgement
condition
172 Theta position compen-
sation upper limit
Set / Get −180 to 180 180 --- Judgement
condition
173 Theta position compen-
sation lower limit
Set / Get −180 to 180 −180 --- Judgement
condition
174 Judge
con-
dit6ion
Disp. Image Selection Set / Get 0: Measurement image
1: Meas. Img.+Model Img.
2: Edge Image
3: Edge Img.+ Model Img.
1 --- ---
178 Edge Level Set / Get 0: No
1: Yes
1 --- ---
179 Mask Size Set / Get
0: 3×3
1: 5×5
2: 7×7
0 --- ---
182 Edge Level Auto Set / Get 0: OFF
1: ON
1 --- ---
184 Acceptable Dist. Level Set / Get
0: Low
1: Medium
2: High
2 --- ---
185 Noise Removal Level Set / Get 0 to 100 0 --- ---
Exter-
nal ref-
erence
number
Category Data name
Set / Get
Data range Default Expression
text string
Logged data/
Judgement
parameter
