Omron FQ2-S/CH Series

External Reference Parameters
494
FQ2-S/CH User’s Manual
183
Judge-
ment
condi-
tions
Edge position Y lower
limit 0
Set / Get −99,999.9999 to 99,999.9999
−99,999.9999
--- Judgement
condition
185 Edge position X upper
limit 1
Set / Get −99,999.9999 to 99,999.9999
99,999.9999
--- Judgement
condition
186 Edge position X lower
limit 1
Set / Get −99,999.9999 to 99,999.9999
−99,999.9999
--- Judgement
condition
187 Edge position Y upper
limit 1
Set / Get −99,999.9999 to 99,999.9999
99,999.9999
--- Judgement
condition
188 Edge position Y lower
limit 1
Set / Get −99,999.9999 to 99,999.9999
−99,999.9999
--- Judgement
condition
190 Position compensation
X upper limit
Set / Get −99,999.9999 to 99,999.9999
99,999.9999
--- Judgement
condition
191 Position compensation
X lower limit
Set / Get −99,999.9999 to 99,999.9999
−99,999.9999
--- Judgement
condition
192 Position compensation
Y upper limit
Set / Get −99,999.9999 to 99,999.9999
99,999.9999
--- Judgement
condition
193 Position compensation
Y lower limit
Set / Get −99,999.9999 to 99,999.9999
−99,999.9999
--- Judgement
condition
310
Logging
condi-
tions
Data logging switch for
entire unit
Set / Get 0: Data logging OFF
1: Data logging ON
0--- ---
311 Data logging switch for
judgement
Set / Get 0: Data logging OFF
1: Data logging ON
0--- ---
312 Data logging switch for
scroll X
Set / Get 0: Data logging OFF
1: Data logging ON
0--- ---
313 Data logging switch for
scroll Y
Set / Get 0: Data logging OFF
1: Data logging ON
0--- ---
314
Data logging switch
for detected edge posi-
tion X0
Set / Get 0: Data logging OFF
1: Data logging ON
0--- ---
315
Logging
condi-
tions
Data logging switch
for detected edge posi-
tion Y0
Set / Get 0: Data logging OFF
1: Data logging ON
0--- ---
316
Data logging switch
for detected edge posi-
tion X1
Set / Get 0: Data logging OFF
1: Data logging ON
0--- ---
317
Data logging switch
for detected edge posi-
tion Y1
Set / Get 0: Data logging OFF,
1: Data logging ON
0--- ---
700
Display
settings
Position compensation
X display
Set / Get 0: ON
1: OFF
0--- ---
701 Position compensation
Y display
Set / Get 0: ON
1: OFF
0--- ---
702 Detected edge position
X0 display
Set / Get 0: ON
1: OFF
0--- ---
703 Detected edge position
Y0 display
Set / Get 0: ON
1: OFF
0--- ---
704 Display
settings
Detected edge position
X1 display
Set / Get 0: ON
1: OFF
0--- ---
705 Detected edge position
Y1 display
Set / Get 0: ON
1: OFF
0--- ---
External
refer-
ence
number
Category Data name
Set / Get
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
