Omron FQ2-S/CH Series User Manual

Specifications and Dimensions
FQ2-S/CH User’s Manual
559
Appendices
9
FQ2-S30-13/-S35-13/-S30-13M/-S35-13M (Unit: mm)
FQ2-S40-13/-S45-13/-S40-13M/-S45-13M
Mounting Base (FQ2-S only) (Unit: mm)
Mounting screw recommended
tightening torque: 0.54 N·m
*1 The shape of opposite side isomorphous.
29 dia.
Optical axis
4-M3
Depth: 4
Mounting hole dimensions
Four, 3.4 dia.
4-M3
Depth: 4
*1
6-M3 Depth: 4
69.5±0.1
26±0.1
9 78 (12.5)
3.5 69.5
26
(3.8)
13
4.5
12.3
6.5
38
38
19
26
3.5 37 32.5
3.5
69.5
26
Mounting screw recommended tightening
torque: 0.54 N·m
80.5
34
18
7.2 20.2
23.5
65
20
Four M4, Depth: 4
Two M3, Depth: 4
1/4-20UNC, Depth: 4
9
3
6
20.2±0.1
16.3±0.1
18±0.1
20±0.1
57.8±0.1
Mounting Hole Dimensions
Two, 3.4 dia.
Four, 4.5 dia.
