Figure 39: Disconnecting Cables
3 Remove the console by lifting it off the mounting hook.
Console Hook and Notch
1 Install the replacement console. In the back of the P80 console
there is a large black steel support called the Armor. At the
bottom of Armor there is a notch about ¼ inches in depth and about
1½ inches across. Set the console notch over the over the mounting
hook.
Note: Before releasing the console insure the notch is securely seated
over the mounting hook.
